5221 Twin Auger

5200 SERIES FORAGE BOX

Features common to all models:

The 5200 Series Forage Boxes are front unload only.
Available in either HD 7-4 (cross conveyor), or HD Twin Auger front unload systems.
PTO front unload drive as standard, and hydraulic drive front unload as optional.
Faster unload time and the smoothest unloading system on the market
New swept back unit design
H&S uses (3) – 18″ 4 Bar Heavy Duty spiral type beaters – not augers. Aggressive in handling tough material, they are even feeding.
Beater shafts are 1¼″ & equipped with greaseable bearings and are mounted in the head, not auxiliary panels in the box.
Full length side screen venting
Easy install 4th beater w/knock-out lugs
A simple trouble-free variable speed drive lets you match just the right unload speed to the crop type, load condition and blower capacity.
A separate clutch allows you to start and clear the cross conveyor or augers before you start the beaters or main apron conveyors.
Heavy 10″ frame stringers
5” – 6 Gauge Steel Channel Cross-Frame Members
2.5″ x 2.5″ tube uprights
2″ Apron Drive Shaft
7+4 Models – Standard Spring Assist 24″ Cross Conveyor Extension has the ability to tip DOWNWARD 22 degrees
Spring loaded tighteners for the beater drive chains
Remote grease zerks for the beater bearings
All models feature a Removable Roof/No Roof Option
